40G QSFP plus LR4
40G QSFP plus LR4 1310nm 10km DOM Duplex LC SMF Optical Transceiver Module Cov Khoom Piav Qhia Lub QSFP ntxiv module yog tsim los siv rau hauv 40GBASE Ethernet throughput mus txog 10km dhau ib hom fiber ntau (SMF) siv lub wavelength ntawm 1310nm ntawm duplex LC cov khoom sib txuas. Qhov no transceiver tau ua raws li QSFP ntxiv ...
- Khoom Taw qhia
40G QSFP ntxiv rau LR4 1310nm 10km DOM Duplex LC SMF Optical Transceiver Module
Khoom Description
QSFP ntxiv module yog tsim los siv rau hauv 40GBASE Ethernet throughput mus txog 10km dhau ib hom fiber ntau (SMF) siv lub wavelength ntawm 1310nm ntawm duplex LC connectors. Qhov transceiver no ua raws li QSFP ntxiv rau MSA thiab IEEE 802.3ba 40GBASE-LR4 thiab OTU3 C4S1-2D1 tus qauv. Digital diagnostics functions kuj muaj nyob ntawm I2C interface, raws li tau teev tseg los ntawm QSFP ntxiv rau MSA, tso cai rau kev nkag mus rau lub sijhawm ua haujlwm tsis muaj sijhawm. Nrog rau cov yam ntxwv no, qhov no yooj yim rau nruab, kub swappable transceiver yog tsim los siv rau hauv ntau daim ntawv thov, xws li cov chaw zov me nyuam, kev ua haujlwm siab hauv kev sib txuas, kev lag luam tseem ceeb thiab kev faib txheej txheej.
Lub hauv paus wavelengths ntawm 4 CWDM raws yog 1271, 1291, 1311 thiab 1331 nm raws li cov tswv cuab ntawm CWDM wavelength kab sib chaws txhais hauv ITU-T G694.2. Nws muaj ib tug duplex LC connector rau optical interface thiab ib tug 38-pin connector rau hluav taws xob interface. Txhawm rau txo qhov kev cuam tshuam ntawm qhov muag pom hauv qhov ntev-ntev, ib hom fiber ntau (SMF) yuav tsum tau siv rau hauv cov qauv no. Cov khoom lag luam yog tsim los nrog cov qauv tsim, kev sib txuas kho qhov muag / hluav taws xob thiab digital diagnostic interface raws li QSFP Multi-Source Agreement (MSA). Nws tau raug tsim los ua kom tau raws li kev ua haujlwm hnyav tshaj plaws nrog rau qhov kub, av noo thiab EMI cuam tshuam.
Daim ntawv pov thawj khoom
Technical Specifications
| Tau tshaj | 40GE QSFP plus LR4 | TX Power | -7 ~ 2.3dBm |
| Lub wavelength | 1310nm ua | Tus txais rhiab heev | ＜-11dBm |
| Txuas | Duplex LC | Hom Transimitter | DFB CWDM |
| Max Data Rate | 44.6 Gbps (4x 11.2 Gbps) | Hom txais | PIN |
| Max Kab nrug deb | 10km ua | Media | SMF |
Technical Specifications
Qhov zoo ntawm 40G QSFP ntxiv rau LR4 module koj tau xaiv yog::
-
Ib qho ntxiv 3.3V fais fab mov ua haujlwm
-
4 CWDM kab MUX/DEMUX tsim
-
Ua raws li QDR / DDR Infiniband cov ntaub ntawv tus nqi
-
Mus txog 11.2Gbps ib channel bandwidth
-
Qhov kub thiab txias 0 degree txog 70 degree
-
Ua raws li 40G Ethernet IEEE802.3ba thiab 40GBASE-LR4 Standard
-
RoHS Ua Raws Li Ntu
Cov ntaub ntawv thov
40G Connectivity rau Data Center
Tshwj xeeb nrog lub zog qis, siab ceev thiab siab ceev, QSFP ntxiv rau transceiver muaj txoj hauv kev nrov los pab koj sai li sai tau mus txog 40G kis tau tus mob.
1
Optical Spectrum Test
Tsis Muaj Pob Poob & CRC
2
Kev Ntsuas Qhov Muag
Mask Margin >20 feem pua
3
Bit Error Rate Test
PEB 1E-12
