1GE XPON ONU
PON yog ib tug paub tab fiber optical nkag network technology, uas integrates qhov zoo ntawm tus nqi qis, siab bandwidth, muaj zog expansibility thiab lwm yam zoo.
- Khoom Taw qhia
ONU Khoom Specifications
PON yog ib tug paub tab fiber optical nkag network technology, uas integrates qhov zoo ntawm tus nqi qis, siab bandwidth, muaj zog expansibility thiab lwm yam zoo. Nws txais cov passive spectral network thiab taw tes-rau-multipoint qauv, uas hloov cov teeb meem uas twb muaj lawm nyob rau hauv lub active optical network xws li ntau yam txhaum, kev kho nyuaj thiab cov nqi khiav hauj lwm siab.
ONU yog tus neeg siv lub davhlau ya nyob twg ntawm nws tus kheej tsim los ntawm FB-LINK nyob rau hauv txoj kab nrog xws li kev lag luam keeb kwm yav dhau los.Cov cuab yeej tau tsim-hauv ob txheej txheej hloov ua haujlwm. Nws yog compact thiab compact, thiab yog FTTH optical network chav tsev nrog kev ua haujlwm siab thiab qis zog noj. ONU tuaj yeem hloov EPON / GPON ua haujlwm hom thiab tuaj yeem siv hauv EPON / GPON network, uas yog qhov tsim nyog rau daim ntawv thov ntawm ntau cov ntaub ntawv kev pabcuam hauv FTTH networking scenarios ntawm ntau tus tswv.
Yam khoom tsom teeb
● GPON ua haujlwm hom Ua raws li IEEE 802.3ah & itu-t g.984.x tus qauv
● Chipset: Realtek 9601D
● GPON: 8 T-CONTs, 32 GEM Ports
● EPON ua haujlwm hom ua raws li IEEE 802.3ah specification thiab OAM raws tu qauv
● Txhawb lub web configuration muaj nuj nqi
● Txhawb SFU thiab HGU hom, tuaj yeem hloov mus siv ib leeg
● HGU hom, Txhawb PPPoE / Static IP / DHCP
● Txheej 2 Hloov, txhawb 802.1Q VLAN, 802.1P QOS, Bandwidth Control, Spanning Ntoo, thiab lwm yam
● Layer 3 Home Gateway/CPE nta nrog Hardware NAT, txhawb Txoj Kev, thiab lwm yam
● Txhawb kev teeb tsa ntawm Ethernet interface tus nqi, hom kev ua haujlwm, MDI / MDIX auto-negotiation hom, thiab Pause flow control
● Muab cov txheeb cais ua haujlwm ntawm txhua kab Ethernet
● Txhawb multicast IGMP snooping
● Txhawb nqa L2 xaim ceev xa mus
● Txhawb AES-128 algorithm rau cov ntaub ntawv encryption ntawm downlink cov ntaub ntawv
Kev piav qhia
Kho vajtseSpecifications | |
Qhov Loj (L * W * H) | 90mm (L) × 90mm (W) × 24 hli (H) |
Optical teeb liab nkag | EPON / GPON |
Tus neeg siv interface | 1 GE |
Qhov taw qhia lub teeb | POWER/PON/LOS/LAN |
Khawm | Fais fab hloov khawm, Pib dua khawm |
Qhov hnyav | 95g |
Fais fab adapter input | 100V -240V AC, 50Hz-60Hz |
PowerSupply xav tau | 12V DC, 0.5A |
Kev siv fais fab | <> |
Ua haujlwm kub | -10 degree ~ ntxiv rau 45 degree |
Ib puag ncig humidity | 5% ~ 95% (tsis-condensing) |
PONIntaj | |
Module hom | SC/UPC |
Ua haujlwm wavelength | nce 1310nm, nqis 1490nm |
TX Optical power value | 0 5-4dbm |
RX Optical zog rhiab heev | -27dBm |
Kev sib kis nrug | 0-20km |
Tus nqi kis tau tus mob | GPON: Uplink 1.244Gbps; downlink 2.488Gbps |
Ethernet interface | |
Hom interface | RJ 45 |
Interface parameters | 1 x 10/100/1000Mbps auto adaptive Ethernet interfaces |
